mauve::runtime::ExecState< CORE > Class Template Reference

Inheritance diagram for mauve::runtime::ExecState< CORE >:

Collaboration diagram for mauve::runtime::ExecState< CORE >:

Public Types
using	Guard_t = std::function< bool(CORE *)>
using	Update_t = std::function< void(CORE *)>

Public Member Functions
	ExecState (ExecState< CORE > const &other)=delete
time_ns_t	get_clock () const override
	Get the clock value of the SynchroState "name". More...
std::size_t	get_next_size () const override
	Return the number of transitions.
AbstractState *	get_next_state (int index) const override
	Return the next state according to the index.
bool	is_execution () const override
	Check if the state is an Execution state.
bool	is_synchronization () const override
	Check if the state is a Synchronization state.
ExecState< CORE > &	operator= (ExecState< CORE > const &other)=delete
bool	set_clock (time_ns_t clock) override
	Change the clock value of the SynchroState "name". More...
bool	set_update (Update_t update)
std::string	to_string () const override
	Return the state as a string.
Public Member Functions inherited from mauve::runtime::State< CORE >
	State (State< CORE > const &other)=delete
State< CORE > &	operator= (State< CORE > const &other)=delete
void	set_next (State< CORE > &next)
Public Member Functions inherited from mauve::runtime::AbstractState
	AbstractState (AbstractState const &other)=delete
AbstractState &	operator= (AbstractState const &other)=delete

Friends
template<typename S , typename C >
class	FiniteStateMachine

Additional Inherited Members
Public Attributes inherited from mauve::runtime::AbstractState
friend	AbstractFiniteStateMachine
std::string const	name
	State name.
Protected Member Functions inherited from mauve::runtime::State< CORE >
	State (AbstractFiniteStateMachine *container, std::string const &name)
Protected Member Functions inherited from mauve::runtime::AbstractState
	AbstractState (AbstractFiniteStateMachine *container, std::string const &name)
Protected Attributes inherited from mauve::runtime::State< CORE >
State< CORE > *	next
Protected Attributes inherited from mauve::runtime::AbstractState
const AbstractFiniteStateMachine *	container

Member Function Documentation

template<typename CORE>

time_ns_t mauve::runtime::ExecState< CORE >::get_clock ( ) const

overridevirtual

Get the clock value of the SynchroState "name".

Returns

the clock value of the SynchroState or 0 if the state is not a SynchroState

Implements mauve::runtime::AbstractState.

template<typename CORE>

bool mauve::runtime::ExecState< CORE >::set_clock ( time_ns_t  clock )

overridevirtual

Change the clock value of the SynchroState "name".

Returns

true if the FSM is not configured and if a SynchroState named "name" exists, false otherwise

Implements mauve::runtime::AbstractState.
